N Series Accessories

Product features:

• Easy to take out and easy to bend: After printing is completed and the temperature of the printing plate drops to room temperature, you can directly hold the handle of the printing plate to remove it. You can gently twist the printing plate to remove the model from the plate. Large models can be easily removed with the help of a scraper.
• Durable: The printing surface can withstand the high temperature of the nozzle and printing plate of the Raise3D printer.
• Easy to use and maintain: You only need to stick it onto the build plate to print. You can use warm water and alcohol to clean the printing surface.
• Applicable to a variety of filaments: Raise3D BuildTak Build Surface is compatible with various filaments up to 300℃: PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill. For the setting temperature of the printing plate for different filaments, please consult to 3D Printing Materials Guide.

Safety warnings:

• How long a Raise3D BuildTak Build Surface lasts depends on the filaments being printed, printing settings and user skills. Please use a smooth/rounded scraper when removing filaments from the printing surface. Do not use a scraper to vigorously remove filaments, otherwise you will damage the printing surface and reduce its service life.
• Do not use solvents such as acetone for cleaning, so as not to damage the printing surface. You can wipe the printing surface with water or alcohol. You can consult How to Clean the Printing Surface.
• When installing Raise3D BuildTak Build Surface, wipe down your bare build platform making sure it is clean and free of debris. Remove the white adhesive liner and apply the BuildTak sheet to the bare build plate. Start from one edge of the build plate and work your way to the other edge, smoothing the BuildTak sheet with a card or a feeler gauge. Make sure that there are no air bubbles between the BuildTak sheet and the build plate after it is pasted.
• Make sure the build plate is level and calibrate the nozzle height to ensure printing accuracy.

Packaging Size (WxDxH): 130x110x5mm

Weight with Packaging: 9g

For Raise3D N series printers.

Product description:

Raise3D N series extruder hot end kit, including a brass nozzle, aluminum heating block, throat pipe (built-in PTFE tube), silicone protective cover. It is suitable for V2 Brass Nozzle 0.4mm (N Series Printer Only) sold on Raise3D’s official website.

Includes:

1x 0.4mm brass nozzle

1x 17.7mm throat tube

1x aluminum heating block

1 x heat sink

For Raise3D N series printers.

Product Specifications:

Product features:

• Applicability and compatibility: Hot End Assembly (V2) (N Series Only) is only compatible with Raise3D N series printer; it is easily to install, and can be inserted directly into the extruder.
• Anti-leakage and anti-clogging design: The nozzle of the extruder is seamlessly connected to the throat tube to prevent leakage or blockage of filaments.
• Heat resistance: The maximum working temperature is 300°
• Nozzle can be replaced: V2 Brass Nozzle 0.4mm (N Series Printer Only) sold on Raise3D’s official website.

Compatible filaments:

• Compatible with various filaments: PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill.

Installation tips:

• When disassembling and assembling the hot end, please power off the printer. The temperature of the hot end can be very high, so please wear the supplied heat-insulating gloves and use needle-nose pliers to perform any intervention.
• Be sure to check all wiring and power supply ratings carefully. It is recommended to perform any intervention on the nozzle only after turning off the power to avoid the possibility of a short circuit and fire.

Product description:

Raise3D Glass Build Plate is made of 100% pure borosilicate glass. Its hardness is as high as 8 Mohs. It can work at a temperature of 400°C, and it heats quickly and evenly. The Raise3D Glass Build Plate is very and smooth, ensuring a smooth and flat base for each printed model and thus obtaining a higher-precision printing result. The glass Build Plate is more durable, able to withstand multiple uses without frequent replacement.

Included:

1×Glass Build Plate

Product specifications:

Packaging Size for N1 (WxDxH): 312×296×35mm

Packaging Size for N2/N2P (WxDxH): 400×395×60mm

Weight with Packaging: 480g

Material: Borosilicate glass

For Raise3D N Series printers.

Printing surface NOT INCLUDED.

Product features:

• High flatness: The improved Raise3D Glass Build Plate is flatter and smoother, ensuring a flat model base, and can accommodate several models.
• Durable and high temperature resistance: It is made of borosilicate glass, and it has strong heat resistance and can work at a temperature of 400ºC. With a hardness of 8 Mohs, it is more robust and durable, so it can be used repeatedly without reducing performance and without frequent replacement.
• Applicable to a variety of filaments: Raise3D Printing Build Surface is compatible with various filaments up to 300℃: PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill. For the setting temperature of the printing plate for different filaments, please refer to the 3D Printing Materials Guide.
• Easy to install: it can be directly placed on the existing heating bed. It is fixed with several clips, which makes it easy to install and remove.
• Easy to clean: After being used many times, it can be taken off and cleaned with water or alcohol. Soapy water can also be used to clean the glass surface.

Safety warnings:

• You need to confirm the nozzle height to prevent the nozzle from being too low and touching the build surface.
• If the model does not adhere to the printing plate, you can apply a layer of PVP solid glue on the surface of the printing plate.
• The glass build plate is fragile, so extra care has to be taken so as not to break it when you either remove it or put it back in the printer.

Product description:

The V2 Brass Nozzle has excellent thermal conductivity, which means it can transfer heat from the hot end to the nozzle and filament more efficiently than other materials. The Raise3D V2 Brass Nozzle is exquisitely designed, with high quality, sturdiness and durability, and suitable for printing with filament up to 300℃, or printing with non-abrasive filament.

Product specifications:

Packaging Size (WxDxH): 130 x 110 x 10mm

Weight with Packaging: 8g

For Raise3D N series printers.

Product features:

• Exquisite design: Raise3D V2 Brass Nozzle is exquisitely designed to effectively prevent filament leakage at the hot end and to provide a smooth, glossy and consistent printing finish. The internal grooves and protrusions are carefully conceived to reduce resistance on corners, and the chamfer design is used to reduce the loss of filament.
• High-quality material: Raise3D V2 Brass Nozzle is made of high-quality brass material, which does not rust or corrode easily. The brass nozzle is durable and easy to install.
• Smooth surface: The smooth surface allows the nozzle to connect to the hot end smoothly to avoid leakage of filament, and achieve a smooth and neat printing finish.
• High precision: The inner wall of the nozzle of the 3D printer extruder is smooth and without burrs, and the viscosity coefficient is low. The diameter variation of the extruder nozzle is less than 0.02 mm, produces smooth extrusion when printing.
• Applicability and compatibility: Raise3D V2 Brass Nozzle is suitable only for Raise3D N Series printers.

Compatible filaments:

Compatible with various filaments: PLA / ABS / HIPS / PC / TPU / TPE / NYLON / PETG / ASA / PP / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill.

Printing tips:

The brass nozzle is suitable for printing non-abrasive filaments such as PLA or ABS that do not contain certain additives. Using filaments with additives such as glass, carbon fiber or metal particles will accelerate the wear of the brass nozzle and greatly reduce its service life.

The grooves and ridges inside the nozzle are prone to damage, which can block the nozzle or increase the diameter of the nozzle orifice and make it unusable.

Tips for filaments:

• The recommended nozzle temperature for Raise3D Premium PLA is 190℃-220℃.
• The recommended nozzle temperature for Raise3D Premium ABS is 245℃-265℃.
• The recommended nozzle temperature for Raise3D Premium PETG is 230℃-240℃.
• The recommended nozzle temperature for Raise3D Premium Nylon is 280℃-290℃.
• For more recommended nozzle temperature of Raise3D Premium official filament, please consult the Filament Guide.

Safety warning:

• During the printing process, the temperature of the nozzle is very high, please do not touch the nozzle directly.
• When disassembling the nozzle and the hot end, please wear the heat-insulating gloves provided to prevent burns.
• After replacing the nozzle, be sure to recalibrate the distance between the nozzle and the printing plate, and also calibrate the height of the left and right nozzles to achieve a smooth printing experience.

Packaging Size (WxHxD): 160x130x65mm

Weight with Packaging: 180g

Print large objects and material intensive pieces fearlessly. The Filament Run-Out Sensor add-on is a job-saving feature that detects when you’ve reached the end of your filament, and saves your project until you can return to reload.

A must-have for manufacturing and production printers.

Filament Run-out Sensor:

The Filament Run-Out Sensor is designed for those who are looking to print intensively jobs and large object prints, fearlessly.

Eliminate the risk of unfinished prints and the waste of half-used filament spools. The Filament Run-Out Sensor monitors your filament and prevents unfinished prints and “air printing”.

For large volume prints that require multiple spools or for specialty filament options prone to breakage, the sensor will automatically detect when material has run out and will pause your project until you to return. Combined with Raise3D print recovery for power outages, this add-on ensures continuous production with your N-Series system.

The Filament Run-Out Sensor detects filaments by using high quality optical sensors compatible with: opaque, translucent, and transparent filaments. This optical sensor maintains constancy and tension without the interference of physical gears or grips, allowing compatibility with multiple material types including flexible filaments. (For translucent/transparent/flexible materials, only Raise3D Branded filament is verified.)

Specs:

Printer Compatibility: Raise3D N1, Raise3D N2, Raise3D N2 Plus

Filament Size: 1.75mm

Filament Types: all Raise3D N-Series compatible materials, including: Opaque, Translucent, Transparent, and Flexible. (For translucent/transparent/flexible materials, only Raise3D Branded filament is verified.)

Thermal Protector:

In the unlikely event of damage in the extruder board cable, the thermal protector is a safeguard to prevent an unmonitored increase in extruder temperature. The installation of the included thermal protector is recommended especially for users who operate the N-series 3D Printers exhaustively.

Submit your request to http://help.raise3d.com with the serial number as well as purchase information for your N-series printer.

You can find the “Filament Run-out Sensor Installation Instruction” and “Firmware” for N-Series printers here. Please update your printer accordingly so the filament run out sensor will work properly.

Packaging Size (WxDxH): 180x150x20mm

Weight with Packaging: 47g

Packaging Size (WxDxH): 130x110x5mm

Weight with Packaging: 8g

For Raise3D N Printers.

Packaging Size (WxDxH): 130x110x25mm

Weight with Packaging: 22g

X Shaft Coupler Replacement Guide
Y Shaft Coupler Replacement Guide

Packaging Size (WxDxH): 160x130x65mm

Weight with Packaging (WxDxH):180g

Features:

• Remote monitoring and control with ideaMaker
• Capture print time-lapse

Benefits:

• Easy monitoring of your 3D printers

Webcam Installation Instruction for N1

Webcam Installation Instruction for N2 & N2 Plus

Packaging Size (WxDxH): 130x110x30mm

Weight with Packaging: 23g

For Raise3D N Printers.

Packaging Size (WxDxH): 230x170x700mm

Weight with Packaging: 575g

Features:

• Dual direct-drive extruder – 4× increased torque performance
• Lightweight

Benefits:

• Eliminate feed issues with its increased torque and controlled feeding
• Enable faster 3d printer speeds with sustained quality
• Increase reliability with flexible materials
• Increase performance and print quality

Bondtech Dual Extruder Installation Instruction

Packaging Size (WxDxH): 180x150x30mm

Weight with Packaging: 110g

For Raise3D N series 3D printers.

Packaging Size (WxDxH): 130x110x10mm

Weight with Packaging: 14g

For Raise3D N series printers.

Packaging Size (WxDxH): 130x110x30mm

Weight with Packaging: 12g

For Raise3D N series printers.

Packaging Size (WxDxH): 130x110x40mm

Weight with Packaging: 9g

TMC2100 Silent Steps.

Packaging Size (WxDxH): 130x110x40mm

Weight with Packaging: 9g

Adjustable a4988 stepper driver (Max 2A).

Packaging Size (WxDxH): 180x150x30mm

Weight with Packaging: 85g

Packaging Size (WxDxH): 180x150x40mm

Weight with Packaging: 106g

For Pro2 Series & N Series Printers.

Installation Instruction
