Ultrafuse® 17-4 PH
Ultrafuse® 17-4 PH
The Filament Enabling Stainless Steel Parts for Applications that Require High Hardness and Mechanical Strength
Ultrafuse® 17-4 PH is a filament for the production of metal components in 17-4 stainless steel on standard Fused Filament Fabrication (FFF) printers.
Specifications: 1.75mm
Spool Size: 3kg
Ultrafuse® 17-4 PH Filament is an industrial material that makes it easy to produce metal-polymer parts on a desktop 3D printer. It is nearly 100% solid 17-4 PH stainless steel. The stainless steel can be fully heat treated to high levels of strength and hardness. It is therefore ideal for Petrochemistry, Aerospace, the Automotive and the Medical Industry. Parts printed with our metal-polymer composite filament Ultrafuse® 17-4 PH obtain their final properties through a catalytic debinding and sintering process known from traditional Metal Injection Molding.
How to Import Slicing Profile to ideaMaker
Delivery
Free ground shipping within continental United States.
For delivery of the USA, expedited delivery availability (additional cost may apply), or additional questions, please contact sales@raise3d.com or 1-888-963-9028.
The shown price excludes tax, which will be calculated during check out.
Benefits at a Glance
- Easy and affordable metal 3D printing
- High mechanical strength and hardness
- Good corrosion resistance
- Fully hardened enables highest strength
- Wide range of post-processing options for green parts
Example Applications
- Tooling
- Jigs and fixtures
- Functional prototypes
Material Properties
- High mechanical strength and hardness
- Easy and affordable way of metal 3D printing
- Good corrosion resistance
- Fully hardened enables highest strength
- Wide range of post-processing options for green parts
Comparison of BASF's Ultrafuse® 316L and Ultrafuse 17-4
| 316L | 17-4 PH |
|
•Stainless steel •Non-magnetic •Excellent corrosion resistance •Excellent weldability •Ductile mechanical properties |
•Stainless steel •Magnetic •Good corrosion resistance •Heat treatable •Very strong mechanical properties |
